TwistClip | Rifle scope adapter for thermal imaging attachments

The new TwistClip is a device holder that easily and securely attaches the attachment to the target optics using a bayonet lock. Thanks to its torsion-proof tooth flanks and the generous thread surfaces, the attachment can only be attached in one position. Thus, the restoration of the point of impact is 100 percent and nothing stands in the way of the success of the hunt for the black coat.

The new Twistclip is a device holder that easily and securely attaches the attachment to the target optics using a bayonet lock. Thanks to its torsion-proof tooth flanks and the generous thread surfaces, the attachment can only be attached in one position. Thus, the restoration of the point of impact is 100 percent and nothing stands in the way of the success of the hunt for the black coat.

The dimensions of the rifle scope's outer diameter must always be taken into account. Each manufacturer has a different dimension. Therefore check the outside diameter before ordering.

DDoptics TwistClip ZFH adapters are suitable for DDoptics rifle scopes with the following lens diameters:

• 56 mm (ZFH 65 mm long)
• 50 mm (ZFH 58 mm long)
• 42 mm (ZFH 50 mm long)

The TwistClip thread adapter is offered in all common thread sizes for a wide variety of devices. Thanks to its supporting lever nose, which is attached to the top center of the outer diameter, opening and closing the adapter is very easy to operate.

The insert can only be locked in one position. This has the advantage, especially with night vision devices when they are put on in absolute darkness, that the device cannot be put on incorrectly and the point of impact is therefore 100% given.

The threaded insert is firmly connected to the NVD or to the TIC using a clamping ring.

• Small clamping range of 15 - 25 mm required
• Can be used for combined arms
• is firmly attached to the lens of the telescopic sight using 4-6 M3 screws (2.5-3 Nm)
• 100% reproducible point of impact
• Attachment can be used on multiple scopes
• Very short design for short barrels with silencer
• 100% Made in Germany
• Aluminum black anodized
• the unit of measurement ZFH ... mm always refers to the outside diameter of the telescopic sight

Due to the very small clamping width of 25 mm (long), it is also possible to equip combined weapons with attachments, which no manufacturer on the market has been able to do so far.

Another significant advantage is the multiple use on different rifle scopes without re-zeroing!!! (initial setting required)
